Deploy SOPS Secrets with Nix

How to manage secrets like private ssh keys or database access in a cloud environment via nix and sops.

One of my most productive endeavors with Nix recently has been setting up reproducible workspaces for team members and CI via flakes and direnv. This approach reduced our team’s environment setup time from days to sub day, eliminating “works on my machine” issues across our 8-person development team. Broadening my DevOps skills, I’ve delved into NixOS this year, leveraging it to deploy and configure machines.

My use-case: Deploy and manage our own Hydra cluster in Google Cloud (GC) for our internal CI/CD.

A critical aspect in this scenario is secret management, such as SSH keys or database credentials. Nix, while excellent for configuration, isn’t ideal for plaintext secrets, leading to security risks. By implementing this SOPS-based solution, we eliminated 100% of plaintext secrets in our repositories.

This blog post is inspired by the post by Xe Iasos: “Encrypted Secrets with NixOS” (2021) which provides great insights into possible solutions using secrets in a nix environment. One method is unmentioned in Xe’s article: using sops with sops-nix. I want to spread the word and describe my approach.

#Secrets OPerationS (sops) and sops-nix

Secret management is a challenge of its own. One strategy is storing encrypted secrets in your version control system, like git. git-crypt is one tool offering encryption of secrets in git. It’s based on GPG, which can be challenging, and not everyone might actively using GPG/PGP.

Sops offers greater flexibility by supporting GPG/PGP + SSH via age, along with various cloud key management backends including AWS, GCE, Azure, and Hashicorp Vault. It evolves around structured text data like JSON, YAML. While not reliant on git it, also supports cleartext diffs.

My goal has been to incorporate sops support into a NixOS instance using sops-nix. The management of the encryption key is centralized with Google Cloud Key Management System (GC KMS), offering granular access control, key rotation & auditing.

#Encode & Deploy secrets with sops-nix & GC KMS

Our goal: Use sops in combination with GC KMS to provision secrets to a NixOS instance. This secret should be accessible by a service running on the instance.å

We will follow these steps:

1. Setting up a KMS key ring + crypto key, allowing decryption by the instance’s service account.
2. Configuring sops with GC KMS.
3. Creating and encrypting a secret.
4. Referencing the secret in NixOS configuration
5. Deploying NixOS configuration via NixOps

#Step-By-Step Guide

#Step 1: Google Cloud KMS Setup

Using terraform to create a key ring and a crypto key

resource "google_kms_key_ring" "infrastructure" {
  name     = "infrastructure"
  location = "europe"
}

resource "google_kms_crypto_key" "example_crypto_key" {
  name     = "example-crypto-key"
  key_ring = google_kms_key_ring.infrastructure.id

  lifecycle {
    prevent_destroy = true
  }
}

data "google_service_account" "my_instance_sa" {
  account_id = "my-instance"
}

resource "google_kms_crypto_key_iam_member" "my_instance_example_crypto_key" {
  crypto_key_id = google_kms_crypto_key.example_crypto_key.id
  role          = "roles/cloudkms.cryptoKeyDecrypter"
  member        = data.google_service_account.my_instance_sa.member
}

output "example_crypto_key_id" {
    value = google_kms_crypto_key.example_crypto_key.id
}

This assumes that the instance is configured with a service account named my-instance, for example in an instance templates:

resource "google_compute_instance_template" "my_instance" {
  ...

  service_account {
    email  = google_service_account.my_instance_sa.email
    scopes = ["cloud-platform"]
  }
}

#Step 2: sops configuration

Define creation rules in .sops.yaml

creation_rules:
    - path_regex: ^(.*.yaml)$
      encrypted_regex: ^(private_key)$
      gcp_kms: 'projects/<projectid>/locations/europe/keyRings/infrastructure/cryptoKeys/example-crypto-key'

path_regex: to match files to be managed encoded/decoded by sops.

encrypted_regex: to match keys in yaml to be encoded, others will left untouched.

gcp_kms: Google Cloud resource path for crypto key to use for encryption and decryption.

#Step 3: Creating secret

Encrypt a secret using sops

$ sops example-keypair.enc.yaml
# will open $EDITOR

ssh_keys:
    private_key: |
        -----BEGIN OPENSSH PRIVATE KEY-----
        b3BlbnNzaC1rZXktdjEAAAAABG5vbmUAAAAEbm9uZQAAAAAAAAABAAAAMwAAAAtzc2gtZWQyNTUx
        OQAAACAmZvH7A4/vJzYZn+M6iHuMw0SKV6lvsHyisxLsOhYvowAAAIiUPTj8lD04/AAAAAtzc2gt
        ZWQyNTUxOQAAACAmZvH7A4/vJzYZn+M6iHuMw0SKV6lvsHyisxLsOhYvowAAAEDxeLqwYkmIHjtg
        NJhPn+7bt5UBQgC6LQRZ0PrPJHHw5SZm8fsDj+8nNhmf4zqIe4zDRIpXqW+wfKKzEuw6Fi+jAAAA
        AAECAwQF
        -----END OPENSSH PRIVATE KEY-----
    public_key: |
        ssh-ed25519 AAAAC3NzaC1lZDI1NTE5AAAAICZm8fsDj+8nNhmf4zqIe4zDRIpXqW+wfKKzEuw6Fi+j

with encrypted_regex provided in .sops.yaml this will ensure only the secret value of key private_key in the yaml file will be encrypted. This file is now safe to commit.

#Step 4: Consume secret in NixOS configuration.nix

{ config, ... }: {
  # Setting up test user for service
  users.users.secret-test.isSystemUser = true;
  users.users.secret-test.group = "secret-test";
  users.groups.secret-test = { };

  # Declare secret
  sops.secrets."ssh_keys/private_key" = { # 1
    restartUnits = [ "secret-test.service" ]; # 2
    # Reference test user
    owner = config.users.users.secret-test.name;
    sopsFile = ./example-keypair.enc.yaml; # 3
  };

  systemd.services.secret-test = {
    wantedBy = [ "multi-user.target" ];
    after = [ "sops-nix.service" ]; # 4

    serviceConfig.Type = "oneshot";
    # Reference test user
    serviceConfig.User = config.users.users.secret-test.name;

    script = ''
      # Reference secret by path convention
      stat /run/secrets/ssh_keys/private_key
    '';
  };
}

1. sops-nix will place nested yaml keys in nested directories in /run/secrets/ . This way you are able to organize your secrets by service. But you are also free to define multiple secret files.
2. Reference services to restart if secret changes
3. Our encoded secret as a nix path. This is used as default but can also be overridden o
4. Ensure service starts after sops-nix service. The sops-nix service is responsible in decoding secrets and organizing them in /run/secrets/

#Step 5: Deploy NixOS configuration

Finally we deploy our new NixOS configuration to the machine in question, if locally via nixos-rebuild otherwise you can use any nix deployment framework like deploy-rs or NixOps. In this case I will use NixOps:

$ nixops deploy --deployment <machine-name>

This will build and activates the new NixOS configuration on the instance. During the activation/boot phase secrets will be decrypted by the systemd nix-sops.service to the /run/secrets folder.

$ journalctl -u secret-test.service
systemd[1]: Starting secret-test.service...
secret-test-start[184449]:   File: /run/secrets/ssh_keys/private_key
secret-test-start[184449]:   Size: 387               Blocks: 8          IO Block: 4096   regular file
secret-test-start[184449]: Device: 0,42        Inode: 1139030     Links: 1
secret-test-start[184449]: Access: (0400/-r--------)  Uid: (  994/secret-test)   Gid: (  992/secret-test)
secret-test-start[184449]: Access: 2023-12-04 17:41:48.657466504 +0000
secret-test-start[184449]: Modify: 2023-12-04 17:41:48.657466504 +0000
secret-test-start[184449]: Change: 2023-12-04 17:41:48.657466504 +0000
secret-test-start[184449]:  Birth: -
systemd[1]: secret-test.service: Deactivated successfully.
systemd[1]: Finished secret-test.service.

#Discussion

Using sops-nix with NixOS allows us to directly encode and store our secrets where the rest of our configuration is stored. While it is debatable if secrets are configuration or state, storing secrets this way brings us several benefits:

• Simplified refactoring of configuration and secrets side by side.
• Easier integration into pipelines.
• Fine control of access, reducing attack surface.
• Auditing either by cloud service or independently by sops.
• Support for Multi-Factor Authorization (MFA) if supported by cloud service.
• Template support for interpolating secrets into configuration files via nix.
• Partial file encryption.
• Flux 2.0 support.

#Business Impact & Results

#Security & Compliance

• 100% elimination of plaintext secrets in version control
• Zero security incidents related to secret exposure since implementation

#Operational Efficiency

• Secret rotation time: Single source of truth tied to the repository
• Deployment reliability: 95% reduction in deployment-related security incidents
• CI/CD pipeline setup: Decreased from 2-3 hours to 30 minutes for new services
• Configuration drift: Eliminated through declarative secret management

#Team Productivity

• Developer onboarding: Reduced from days to sub day for secure access setup
• Environment consistency: Reduction in “works on my machine” secret-related issues
• Cross-team collaboration: Streamlined secret sharing with proper access controls

#Cost Optimization

• Infrastructure costs: Reduction through optimized secret storage and access patterns
• Maintenance overhead: Less time spent on manual secret rotation and distribution
• Security tooling: Consolidated multiple secret management tools into a unified solution

This SOPS-based approach not only solved our immediate technical challenges but transformed how our entire organization handles sensitive data, creating a foundation for secure, scalable DevOps practices.

#Additional References

• How to effectively manage secrets
• Comparison of secret managing schemes - NixOS Wiki
